矩形高频率色标传感器KT3W-P1116
2021-07-03 19:55725
信息概况
  • 价格：￥0.00/PCS
  • 起订：1PCS
  • 供应：1000000PCS
发送询价
矩形高频率色标传感器KT3W-P1116
Features
Sensing distance:12.5 mm
Sensing distance tolerance:± 2 mm
Light source 1):LED
Wave length:470 nm, 525 nm, 640 nm
Light spot size:1.5 mm x 6.5 mm
Light spot direction 2):Vertical
Type of light:Visible blue light, Visible green light, Visible red light
Dimensions (W x H x D):12 mm x 40 mm x 22 mm
Housing design (light emission):Rectangular
Teach-in mode:Static 2-point teach-in


Mechanics/electronics
Ripple 1):≤ 5 Vpp
Power consumption 2):< 35 mA
Switching frequency 3):10 kHz
Response time 4):50 µs
Output type:PNP: HIGH = VS- ≤ 2 V / LOW approx. 0 V
Switching mode:PNP
Input, teach-in (ET):PNP:, Run: U < 2 V, Teach: U = 10 V ... < UV
Retention time (ET):25 ms, non-volatile memory
Connection type:Connector M12, 4-pin
Protection class 5):II
Circuit protection:Output Q short-circuit protected, Interference pulse suppression, UV connections, reverse polarity protected
Enclosure rating:IP 67, IP 67
Weight:11 g
Housing material:ABS, Plastic
Output current Imax.:100 mA
Supply voltage:12 V DC ... 24 V DC 6)


Ambient data
Shock load:According to IEC 60068
UL File No.:NRKH.E181493 & NRKH7.E181493
Ambient operating temperature:-10 °C ... +55 °C
Ambient storage temperature:-20 °C ... +75 °C
