条状蜂蜜包装机 防夹料防渗漏 袋装儿童护肤霜膏体酱体包装机

供应条状蜂蜜包装机 防夹料防渗漏 袋装儿童护肤霜膏体酱体包装机

QD-140系列多功能自动包装机

一、特点及用途：
1、该机采用背部封口又称枕式包装机，包装形式美观、计量精度高；

2、采用多路控温热封机构，具有温度控制准确、热平衡良好、保证封口质量、适用多种包装材料等特点；

3、颗粒机采用摇盘式容杯调整装置，可在机器运行过程中随时调整包装容量，减少物料损失，提高工作效率；

4、粉剂机采用料斗升降装置，便于调整利于清洗省去清洗后的再次调整，提高工作效率；

5、液体包装机泵体全部采用不锈钢材料，包装量可在额定范围内无级调整，可包农药、化妆品、液体或半流体。

二、性能参数：

型     号	QD-140
包装速度(袋/分)	40～80
计量范围 (毫升)	1-150
制袋尺寸(毫米)	L:30-190  W:20-155
功     率(千瓦)	0.9
重     量(公斤)	200
外形尺寸(毫米)	700× 800×1650

注：变更成形器可调整制袋尺寸长和宽。



DXD-140Type Multi-function Automatic Packaging Machine

Main characteristic

1. Back sealing or three sides sealing. Pretty package form and count accurately.

2. Use multi path temperature controlling and heat sealing organ, controlling temperature accurately, good heat balance and high quality of sealing. Suitable for packing multi materials;

3. Granule packing machine use shaking container to adjust the device adjusting the package capacities at random in the process to improve the working efficiency. Packing materials are like desiccant, tea and medicine and so on.

4. Powder packing machine use the latest hopper feeder which can be changed its height freely in order to avoid the readjustment after cleanout and improve the working efficiency. Packing materials are like albumen powder, coffee and flour.

5. Liquid and catsup packing machine makes use of stainless steel. Due to applying domestic advanced suction technology, there is no material pressed and leaked. Package capacity can be adjusted infinitely in stated range. Be suitable for packing honey, pesticide and cosmetic and so on

.

Specification:

Model	DXD-140
Packing Speed	40～80 bag/min
Measuring Range	1-150ML
Bag Dimension	L:30-190mm; W:20-135mm
Power	0.9 KW
Weight	200KG
Outline Dimension	700× 800×1650mm

QD-1000B中封单膜液体包装机

一、主要特点：

本机是我厂开发制造的立式、三边封合、间歇式高精度液体包装机。制袋、充填、封合、打印批号、切断、计数等全过程自动完成，微处理器控制，光电眼自动跟踪色标，定位准确可靠，尤其适用酱油、酒、醋、果汁饮料、配制饮料、豆奶、牛奶、花生油、菜油及各种植物油、矿泉水和液体化工产品的单膜袋状。

二、性能参数：

型号	QD-1000 B
生产速度	1800Bags/H
包装容量	50～500ml
电源电压	AC220V/50Hz  、AC380
供纸电机	25W/220V
热封功率  纵封/横封	300W/500W
电机功率	370W/380V/220V
外形尺寸	950× 800×2000 mm
整机重量	300Kgs
型号	QD-1000













QD-1000Bmiddle seal single film packing machine

I．Main characteristic

This machine is a vertical type machine,it seal three sides,intermittenthigh-accuracy liquid packing machine.It can automatic complete the full process of bag-making,fill,seal,print number,cut and counting and so on,be controlled by microprocessor,the photoelectricity eye automatic track colour code , allocated accurately and reliablely , it is the most advanced liquid object in domestic market at present,especially suitable to pack the single and compound films,such as pack sauce,liquor,vinegar,soft drinking,soymilk,milk,peanut oil,vegetable oil,and various plant oil , mineral water and liquid chemical products.

II．Performance parameter

Model	QD-1000 B
Speed	1800Bags/H
capacity	50～500ml
power	AC220V/50Hz  、AC380
Confession paper electric motor	25W/220V
heat-seal power longitudinal seal/ transversal seal	300W/500W
Hotor power	370W/380V/220V
Outline dimension	950× 800×2000 mm
Machine weight	300Kgs
