2. Multi-function thermal alarm system
3. Optional KM-088G (keyboard and touch pad module)
4. Flexible driver combination
5. PICMG 1.3 backplane and Redundant power supply support
6. Advanced air-flow design 特点详情
| LCD Size | 6.5 “ |
| Resolution | 640 x 480 (VGA) |
| Brightness(cd/㎡) | 400 cd/m2 |
| Contrast | 550:1 |
| Viewing Angle | 140 / 120 |
| LCD color | 262k |
| Construction | Heavy Duty metal |
| Backlight MTBF(Hrs) | 50000 hrs |
| Indicators | 1.Temperature 2.LAN 3.Fan |
| Solt | 14 slots for EC -1040G 7 slots for EC-1040GATX |
| Buttons | 1.Power switch 2.System reset |
| Form Factor | EC-1040GB – Full size slot CPU card EC-1040GBATX – ATX or Micro ATX |
| Drive Bays | 3 x 5.25” + 1 x 3.5” |
| Cooling Fans | 2 x 8 cm |
| Option Touch Screen | Optional 4-wire resistive type with RS-232 interface |
| I/O openings | 2 x COM, 1xPS/2 |
| Vibration | 5~17Hz 0.1” double amplitude displacement 17~640 Hz 1.5G acceleration peak to peak |
| Shock | 10Gacceleration peak to peak (11ms) |
| Relative Humidity | 5 ~ 95% @ 60° C, non-condensing |
| Operating Temperature | 0 ~ 50°C |
| Color | Black |
| Weight (Net/Gross) | 15.3kg/ 28.8kg |
| Dimensions (DxWxH)(mm) | 480mmx 431mm x 176mm |
| EC-1040GB / A130A-R30 | 4U Rack mount LCD chassis with 6.5" 800 cd/m² VGA TFT LCD, ACE-A130A-R10, RoHS |
| EC-1040GB / A130A / R-R30 | 4U Rack mount LCD chassis with 6.5" 800 cd/m2 VGA TFT LCD,ACE-A130A-R10 and touch screen,RoHS |
| EC-1040GBATX / A130A-R30 | 4U Rack mount LCD chassis for ATX MB with 6.5" 800 cd/m² VGA TFT LCD,ACE-A130A-R10,RoHS |
| EC-1040GBATX / A130A / R-R30 | 4U Rack mount LCD chassis for ATX MB with 6.5" 800 cd/m² VGA TFT LCD,ACE-A130A-R10 and touch screen,RoHS |
