Specifications:
| Number | Item | Unit | Deion | Remark |
| Customer Interface | ||||
| 1 | RF Connector | F-female | ||
| 2 | Optical Connector | SC/APC | ||
| 3 | Power Adapter | DC2.1 | ||
| Optical Parameter | ||||
| 4 | Optical Return Loss | dB | ≥45 | |
| 5 | Output Optical Wavelength | nm | 1310 | |
| 6 | Output Optical Power | mW | 10 | 10dBm |
| 7 | Optical Fiber Type | Single Mode | ||
| RF Parameter | ||||
| 8 | Frequency Range | MHz | 45~1000 | |
| 9 | Flatness | dB | ±0.75 | |
| 10 | RF Input Level | dBμV | 80±5 | |
| 11 | Input Impedance | Ω | 75 | |
| 12 | Return Loss | dB | ≥14 | |
| 13 | C/N | dB | ≥52 | |
| 14 | CSO | dB | ≥65 | |
| 15 | CTB | dB | ≥62 | |
| Other Parameter | ||||
| 16 | Power Supply | VDC | 12 | |
| 17 | Power Consumption | W | <2 | |
| 18 | Dimensions | mm | 105x84x25 | |
