AC/DC Current Probes – CP3 – SERIES Accurate, Rugged, Versatile and Reliable · Two models Multimeter (CP30) and Oscilloscope (CP35 and CP305) · AC / DC low current measurement down to mAmps · Excellent Accuracy with 1mA resolution (CP30/CP35) · DC Auto Zero and Auto Power Off · Compact lightweight design · Broad bandwidth and low phase shift for power and harmonics measurement · Superior noise rejection for power electronics applications
TYPICAL APPLICATIONS · Light industrial and residential electrical installation testing · Leakage current measurements · Process control for 4 – 20mA current loop verification · Battery charging systems · Analysis of switching waveforms in inverters, switch mode power supplies and industrial controls · Automotive applications eg., Leakage current measurement on car battery lead, detection of ECU sleep mode and current profiling, all requiring high accuracy and superior resolution
Current Range (s)：30 / 300A RMS Output Sensitivity：1mV/A Frequency Range：DC to 20kHz (-3dB) Resolution：± 100mA Basic Accuracy： ± 1% of reading ± 50 / ±100mA Conductor position sensitivity：< ± 1% relative to centre reading Phase shift (up to 1kHz)：< 2 degrees Load Impedance：> 100 kOhms Output connection：Safety BNC connector
